項目Items
|
單位Unit
|
XQT2014A
|
XQT2016A
|
XQT2018A
|
最大加工尺寸Max.milling size
|
長Length
|
mm
|
4000;6000;8000
|
4000;6000;8000
|
寬Width
|
mm
|
1600
|
1800
|
2000
|
高Height
|
mm
|
1000(1200)
|
兩立柱間距Distance between columns
|
mm
|
1820
|
2020
|
2220
|
最大加工件重量Max.milling weight
|
kg
|
1000
|
工作臺運行速度Table speed
|
進給Feed
|
mm/min
|
30—315
|
80—300
|
80—300
|
快移Rapid travel
|
5000
|
工作臺寬Table width
|
mm
|
1400
|
1600
|
1800
|
銑頭前端規格Spindle nose size of milling head
|
|
No.50(7:24)
|
銑頭伸出行程Stretch shifting of milling head
|
mm
|
+100 -200(滑枕 slider)
|
銑頭主軸轉速Spingdle speeds of milling head
|
rpm
|
70—675
|
銑頭回轉速度Swing angle of milling head
|
|
±30°
|
推蔫刀盤最大直徑
Cutter diameter recommended
|
mm
|
φ200
|
垂直銑頭進給速度
Feedrate of vertical milling head
|
mm/mmin
|
30;145;810
|
側銑頭進給速度
Feedrate of side milling head
|
mm/mmin
|
160—800(無級stepless)
|
銑頭電機功率
Motor power of milling head
|
kw
|
11
|
機床外形尺寸Overall dimensions
|
長Length
|
mm
|
11340;15090;19740
|
寬Width
|
mm
|
3797
|
3997
|
4197
|
高Height
|
mm
|
3885
|
3885
|
3885
|
機床凈重Net weight
|
kg
|
37000;43000;49000
|
40000;46000;52000
|
44000;49000;55000
|
