項目Ltema
|
單位Unit
|
CT6140A,B
|
CT6140A,B
|
CT6150A,B
|
CT6250A,B
|
CT6166A,B
|
CT6266A,B
|
|
床身上最大回轉直徑
Max.swing over bed
|
mm
|
400
|
500
|
660
|
|
刀架上回轉直徑
max,swing dia ,dia over carriage
|
mm
|
210
|
300
|
410
|
|
馬鞍內回轉直徑max,swing dia in gap
|
mm
|
|
630
|
|
720
|
|
870
|
|
兩頂尖間距離distance between centers
|
mm
|
500;1000;1500;2000;3000;3500
|
|
主軸通孔直徑bore through spindle
|
rpm
|
A型type:70 B型type:81
|
|
主軸轉速范圍（24級）
range of spindle speeds(24grades)
|
rpm
|
11-1400
|
|
進給量范圍(64種)range of feeds(64kinds)
|
|
標準standsrd feeds 0.04-1.34小進給fine feeds 0.01-0.04
|
|
加工螺紋范圍range of threads to be machined
|
Mm
|
公制螺紋46種metric 46kinds1-288
|
|
英制螺紋47種whitworthc 47kinds1/8-36
|
|
模數螺紋42種module 42kinds 0.5-144
|
|
徑節螺紋53種diametral pitch 53kinds1/4-72
|
|
主電機功率power of main motor
|
Kw
|
7.5
|
|
機床凈重weight
|
500
1000
1500
2000
3000
|
kg
|
1780
|
1860
|
2020
|
|
2090
|
2150
|
2333
|
|
2240
|
2300
|
2483
|
|
2580
|
2640
|
2823
|
|
2800
|
2940
|
3123
|
|
機床外型尺寸
Overall dimensions
|
500
1000
1500
2000
3000
|
mm
|
2070×1050×1260
|
2070×1090×1310
|
2070×1160×1385
|
|
2680×1050×1260
|
2680×1090×1310
|
2680×1160×1385
|
|
3180×1050×1260
|
2680×1090×1310
|
2680×1160×1385
|
|
3680×1050×1260
|
3680×1090×1310
|
3680×1160×1385
|
|
4680×1050×1260
|
4680×1090×1310
|
4680×1160×1385
|
